ESD Table Mat

ESD Table Cushion

ESD Table Cushion
Model:EC1001
Size:1m*10m,1.2m*10m,and Customized size acceptable
Type:No smell or slight smell
...
Chat Now

Smooth finished natural rubber ESD Table Cushion


1.ESD Table Cushion specification

Anti-static bench mat, also known as esd table mat, anti-static rubber sheet, anti-static rubber mat and so on.

Color:Dull/Shiny green,Dull/Shiny grey,Dull/Shiny green,Dull/Shiny blue, Dull/Shiny black.

Standard size:1m*10m.1.2m*10m,0.6m*10m,0.5m*10m etc.

Customized size: Acceptable.

Customized color:Acceptable.

Surface resistance: 10e6-10e9Ω

Bottom resistance: 10e3-10e5Ω

Volume resistance: 10e5-10e8Ω

Wear rate: 0.02g/cm2

Electrostatic removal time: < 0.1s

Ready stocks available or not:Yes

Heat Resistance:300 degrees


2.Application for esd mat roll

esd mat.jpg

3.Anti-static rubber table mat features

The anti-static mat is mainly made of materials such as conductive materials, static dissipative materials and synthetic rubber through various processes. The product is compounded by two layers of rubber, the upper layer is a static dissipative layer and the bottom layer is a conductive layer. The main function of the anti-static table mat is to release the static electricity of the human body, so that the ESD tweezers, tools, instruments, instruments and other articles used in the human body and the work can reach a uniform potential, so that the static sensitive device (SSD) in the production is not affected by static electricity. The interference caused by the discharge phenomenon achieves the electrostatic protection effect, effectively buffering and avoiding device damage. Yida anti-static rubber sheet is soft, strong rebounding force, tear-resistant, wear-resistant, easy to clean, free from high temperature, cold and humidity, and the technical index is stable. The product is flat and does not curl during operation and installation, saving time and effort for customers!


4.ESD Rubber Table Cushion detailed images

esd mat grey.jpg

esd mat roll.jpg

anti-static green mat.jpg


5.SGS and CE Certificates for ESD Table Cushion

ESD green mat1062.png

6.FAQ

1)Why choose us?

●High Quality Products At The Lowest Prices

●10 years manufacturer directly supply

●Fast Dispatch Times

●Rapid Response Times

●Price Matching Available

2)What's the lead time for ESD cushions?

Lead time:3-10 days.

3)How long have you manufacturing and exporting esd products?

More than 10 years.We have our own factory producing esd mat,esd pvc curtain,esd stationery!

7.Payment

TT(Telegraphic Transfer),Western Union,Paypal.Also accept monthly payment for current clients.

esd products payment.jpg

8.Delivery

Lead time:7-10 days for bulk order,1-3 days for small order.

ESD green mat3520.png

esd mat on truck.JPG

Payment and delivery.jpg
